Shuttle XPC Slim series DH670 supports Intel® 12th-Gen Alder Lake hybrid architecture which combines high-performance cores along with high-efficiency cores and moreover supports a 65W base power processor with maximum up to 16 cores and 24 threads. With the brand-new Intel® UHD graphic processor integrated, the model can deliver incredible clarity for 4K/60P UHD resolution so as to bring more achievement on AI and computer vision applications. As for its display productivity and flexibility, DH670 supports quad displays via two HDMI 2.0b and two DisplayPort.
Despite its 1.3L slim chassis design, DH670 offers multiple interfaces to deliver expandability and connectivity where it matters, including a dual Intel® Gigabit Lan, two RS232, an SD card reader, two M.2 expansion slot, four USB 3.2 Gen2, and four USB 3.2 Gen1 (includes one Type-C). In sum, this stable and efficient DH670 is suitable for wide range of application, such as digital signage and kiosk.
Support Alder lake-s LGA1700 socket Core i3/i5/i7/i9, Pentium, Celeron 65W processor
Intel H670 Express chipset
2 x DDR4 SODIMM slots,32GB per DIMM (Max 64GB)
HDMI 2.0 x 2+ DisplayPort x 2, Quad video outputs
Realtek ALC662/897/888S High Definition Audio
Intel I210/I211*2 Dual Lan
SATA 6.0Gb/s interface
(1) 4pin fan connector
Windows 10/11 64 bit O.S
(2) USB 3.2 Gen1 ports
(2) RJ45 Gigabit LAN port w/LED
(1) M.2 2280 Type M key socket
|Dimensions||190(L) x 165(W) x 43(H) mm|
(1) 2.5" HDD / SSD bay
